SYME CARBON FOOT

Syme Carbon Foot features a flexible design that allows it for both indoor and outdoor use. PR.01.K3 Syme also provides perfect stability and safe ground contact. Recommended for prosthetic users with mobility grade 1 and 2.

SYME CARBON FOOT

Syme Carbon Foot features a flexible design that allows it for both indoor and outdoor use. PR.01.K3 Syme also provides perfect stability and safe ground contact. Recommended for prosthetic users with mobility grade 1 and 2.

Stock Code: PR01.K3.2*L

Category: Carbon Foot

-
+
24 months limited warranty.
ISO 9001, 13485, 45001, 14001 and 13485
EC (CE) Declaration of Conformity.

Syme Carbon Foot features a flexible design that allows it for both indoor and outdoor use. PR.01.K3 Syme also provides perfect stability and safe ground contact. Recommended for prosthetic users with mobility grade 1 and 2.

Its constructed sole plate and upper attachment point make the product suitable for very active and heavy patients.

  • Carbon Fiber

  • Heel Height 10 mm

  • Max Body Weight 100 kgs

PR01.K3 is a flexible and light carbon foot, specially designed for patients with a lower extremity Syme’s amputation. The upper part of the foot features a carbon-fiber plate whereas the toes are composed of two carbon sheets. The foot is suitable with a steel rotating lamination anchor.

PR01.K3 is available in sizes from 22-29 cm and provides flex-assist at toeoff and heel. The dynamic dorsi-flexion and improved loading response reduce energy consumption and minimizes ground reaction force. The hard surface shows extra resistance to stress making it specially suitable for heavy patients during their daily activities. To be used with carbon socks and foot shells for carbon feet.

Advice for technicians: The static settings must be made very carefully by correctly determining the connecting points of the lamination adapter.
